INFORMATION ABOUT
FLEXBOARD®
Flexboard combines our unique base layer manufacturing process with a 0.080″ hardboard face to create a flexible and extremely stable base layer that allows easy attachment of high-pressure laminates, veneers, metals and many other semirigid materials. When using Flexboard the decorative surfacing material is applied after the base material has been formed into the desired shape achieving an 8″ bending radius.
Face Materials
Eucalyptus Hardboard (Standard)
Core Materials
Particleboard (Standard)
Plywood
MDF
NAUF Particleboard
Fire Rated Option
NAUF Particleboard
Flame Spread Rating: ASTM E 84: Class A (Core Only)
Flame Spread Rating: ASTM E 84: Class A (Core Only)
Forest Stewardship Council® (FSC®) Certified Option
NAUF Particleboard (License #FSC-C008429)
Assist in qualification of LEED credits MR7 and possibly MR 5.1 and MR 5.2 depending upon project location.
Assist in qualification of LEED credits MR7 and possibly MR 5.1 and MR 5.2 depending upon project location.
Maximum Bending Radius
8"
Bending Radius
Bending radius is directly related to the decorative surfacing material being applied to Flexboard. While a smaller radius may be obtainable, it is best to test before proceeding.
Nominal Thickness
| 1/2" | 5/8" | 3/4" | 11/16" | ||
|---|---|---|---|---|---|
| Particleboard | |||||
| Plywood | |||||
| MDF | |||||
| NAUF Particleboard | |||||
Panel Sizes
| 48" x 120" | 48" x 96" | 96" x 48" | 120" x 48" | ||
|---|---|---|---|---|---|
| Particleboard | |||||
| Plywood | |||||
| MDF | |||||
| NAUF Particleboard | |||||
Decorative Surfacing Materials
High Pressure Laminates
Veneers
Metals
Paint
Adhesive Option for Lamination
Contact Adhesive
Recommended when using a J-Roller
PVA Glue
Recommended when using a Press Machine
Attachment Methods
